Product Summary
The MAX303ESE+T is a precision, dual, high-speed analog switch. The single-pole double-throw (SPDT) MAX303ESE+T has two NO and two normally closed (NC) poles. The applications of MAX303ESE+T are Sample-and-Hold Circuits, Military Radios, Test Equipment, Communication Systems, Heads-Up Displays, Battery-Operated Systems, Guidance and Control Systems, PBX, PABX. It is fabricated with Maxim’s new improved silicon-gate process for high system accuracy.
Parametrics
MAX303ESE+T absolute maximum ratings: (1)Voltage Referenced to V-: V+:44V, GND:25V; (2)VL:(GND-0.3V) to (V+) +0.3V; (3)NO_, NC_, IN_, COM_:(V- - 2V) to (V+ + 2V) or 30mA,whichever occurs first; (4)Continuous Current, COM_, NO_, NC_:30mA; (5)Peak Current, COM_, NO_, NC_(pulsed at 1ms, 10% duty cycle max):100mA; (6)Continuous Power Dissipation (TA = +70℃):696mW; (7)Operating Temperature Ranges::-40℃ to +85℃; (8)Storage Temperature Range:-65℃ to +150℃; (9)Lead Temperature (soldering, 10sec):+300℃.
Features
MAX303ESE+T features: (1)Low On Resistance <22Ω Typical (35Ω Max); (2)Guaranteed Matched On Resistance Between Channels <2Ω; (3)Guaranteed Flat On Resistance over Full Analog Signal Range Δ3Ω Max; (4)Guaranteed Charge Injection <15pC; (5)Guaranteed Off-Channel Leakage <6nA at +85℃; (6)Single-Supply Operation (+10V to +30V) Bipolar-Supply Operation (±4.5V to ±20V); (7)TTL-/CMOS-Logic Compatible; (8)Rail-to-Rail Analog Signal Handling Capability.
